With the DLE-30, you get the economy of a gas engine in the size of a glow engine. Electronic ignition provides the spark for fast starting. Timing automatically adjusts for peak power throughout the rpm range. And a made-for-flight design ensures the best power-to-weight ratio for performance. A rear-mounted pumper carb ensures easier installs and smooth idling before you fly — and dependable fuel flow while you are flying.
Categories:
Specifications

With the DLE-30, you get the economy of a gas engine in the size of a glow engine. Electronic ignition provides the spark for fast starting. Timing automatically adjusts for peak power throughout the rpm range. And a made-for-flight design ensures the best power-to-weight ratio for performance. A rear-mounted pumper carb ensures easier installs and smooth idling before you fly — and dependable fuel flow while you are flying.

Performance: 3.7HP/8500rpm
Idle Speed:1600 rmp/min
Static Thrust:8.5kg/100 metersAltitude
Static Thrust:7.5kg/1800 metersAltitude
Recommended Propeller:18×8 ; 18×10 ; 19×8 ; 20×8 ;
Spark Plug Type: NGK CM6
Displacement:30.5cm3
Diameter x Stroke:36mm×30mm
Compression Ratio:7.6:1
Lubrication Ratio:30:1
Weight of Main Engine: 920g
Weight of Exhaust:60g
Weight of Ignition:130g
Ignition voltage:4.8V-8.4V
