Mugin-3 Pro 3220mm V-Tail Carbon Fiber UAV Platform is a state-of-the-art unmanned aerial vehicle designed for professional applications. This cutting-edge UAV platform is the epitome of engineering excellence, offering unparalleled performance and durability.

Material Upgrade for Unmatched Durability

Gone are the days of balsa wood; the Mugin-3 Pro is now constructed with high-grade carbon fiber. This material upgrade not only enhances the structural integrity of the UAV but also significantly reduces its empty weight. The result? A robust yet lightweight airframe that stands the test of time.

Aerodynamic Excellence

With a wingspan of 3220mm and a length of 2438mm, the Mugin-3 Pro is designed for optimal aerodynamic performance. Its V-Tail configuration further adds to its stability and control, making it a reliable choice for various aerial tasks.

Power-Packed Performance

The UAV is engineered to carry a maximum payload of 8kg and has a maximum take-off weight of 28kg. Whether it’s surveillance equipment or scientific instruments, the Mugin-3 Pro can handle it all.

Speed and Endurance

The Mugin-3 Pro is not just about carrying capacity; it’s about how fast and how long you can achieve your mission. With a cruise speed of 75mph and a maximum speed of 100mph, this UAV is built for speed. Add to that a maximum flight time of 3 hours, and you have a UAV that covers more ground in less time.

Fuel Efficiency

Designed for long-endurance missions, the Mugin-3 Pro can fly up to 3 hours on just 6 liters of fuel. This makes it an economical choice for extended operations.

Customizable Power Packages

The Mugin-3 Pro offers flexibility with its power options. Choose between the recommended gasoline power package for $2150 or the electrical power package for $1950 to suit your specific needs.

Safety and Reliability

With features like a stall speed of 25mph and a range restricted only by its flight time, the Mugin-3 Pro prioritizes safety without compromising on performance.

In a Nutshell

The Mugin-3 Pro 3220mm V-Tail Carbon Fiber UAV Platform is a versatile, durable, and high-performance UAV designed for professionals. Its advanced features and customizable options make it the go-to choice for a wide range of applications.

Specifications:

Wingspan: 3220mm
Length: 2438mm
Empty Weight: 12.45kg
Maximum Take-off Weight: 28kg
Maximum Speed：35m/s
Cruise Speed: 30m/s
Stalling Speed: 24m/s
Maximum Payload: 8kg
Volume of Fuel Tank:10L
Endurance: 4Hours
Flight Range: 400km
Wind Resistance:固定翼6级
Take off distance:50 meters
Landingdistance:70 meters

Recommended Gasoline Power Package (not included) – US$2150.00

DLE60 Engine x 1
Savox 1256 x 7
23×9 High Power Propeller x 1
AT23D Long UAV Pitot Tube x 1
Nav. LED lights x 1 set
Build Kit x 1

Recommended Electrical Power Package (not included) – US$1950.00

Dualsky GA6000.8 180RPM/V Brushless Motor x 1
Dualsky XC13036HV 130A High Voltage ESC x 1
Savox 1256 Servo x 5
24×12 High Power Propeller w/ Prop Cover x 1
AT23D Long UAV Pitot Tube x 1
Nav. LED lights x 1 set
Build Kit x 1

Package Size: 300.0 * 200.0 * 100.0 ( cm )
Gross Weight/Package: 24.0 (kg)
